Mechanical Services

Machining and Mechanical Design Shop

Brian-Devine.jpgBrian Devine

The machining and mechanical design shop at Crocker Nuclear Laboratory (CNL) provides a full range of services, including designing parts and devices, creating prototypes, and fabricating and testing the final product.

Our skilled machinists operate and program some of the most sophisticated machinery and software in the trade. Working in close collaboration with CNL’s fully-appointed electronics shop located in the same work space, they can design, fabricate and test an exceptionally wide array of components tailored to suit a myriad of specific needs.

In addition, they can design and assemble parts on screen using 3D CAD solid modeling, assuring proper fit and function before fabrication. They also use exploded views with details of parts and hardware to aid in the assembly of the system. Complete design documentation is available.

Utilizing sophisticated CAM software, our 3D solid models can be translated into CNC machine code to efficiently produce precision parts on the CNC mill and lathe.

As of January 1, 2017, the Division of Mathematical and Physical Sciences (MPS) administers the MPS Shop, combining the personnel and expertise of the Machine and Mechanical Shop from the Crocker Nuclear Lab with those of the Physics & Chemistry Departments to provide enhanced services under one roof at the Crocker Nuclear Lab in Jungerman Hall.

Contact

To place an order or to discuss rates and scheduling or other questions:

530 752-9908

mpsshop@ucdavis.edu

Services

  • Full machine & mechanical shop
  • 3-axis CNC milling
  • CNC turning
  • Full CAD/CAM interface
  • Complex surface and contour machining
  • Sheet metal fabrication
  • Welding, brazing & soldering
  • Mechanical repairs
  • System fabrication & assembly
  • Parts duplication for analytical systems & research instruments
  • SolidWORKS CAD software
  • Parts, assembly & system design
  • Complex research apparatus
  • Medical devices
  • Biomedical research devices
  • Electro pneumatics
  • Air sampling
  • Custom analytical systems
  • Vacuum systems (for vacuum pumps, see below, MPS departments only)
  • Integrated electronic & computer controls
  • Design enhancement & documentation for patent preparation & application

 MPS Vacuum Pump Service Procedures (for MPS departments ONLY)

  1.  User will submit a request to mpsshop@ucdavis.edu with pump info:

                a. Make

                b. Model

                c. Serial number

                d. Whether the pump needs service or is broken

                e. If Lab pump, recharge account to charge for repair

       2. MPS Shop will get preliminary quote from vendor (vendor will provide revised quote once they have it and inspect it)

           then send the quote to the user along with the hazmat clearance form for the user to fill out and approve.

       3. User will deliver pump to the MPS Shop along with hazmat clearance form.

       4. MPS Shop will send it to the vendor for service.

       5. Vendor will send the pump to the MPS Shop when service is completed.

       6. MPS Shop will contact the user that their pump is ready to pick up.

       7. If a backup pump is available, the MPS Shop will load the user one until theirs is ready to pick up.



Equipment

Machining and fabrication

1 ea. HAAS VF2 CNC Vertical Machining Center: 36" x 14" table, 30" x 16" x 20" travels, 40 taper, 30 hp

2 ea. ACER CNC knee mills, 10 x 50 table, 25”X x 14”Y x 4.5”Z Travel 3-axis anilam 3000M controllers

1 ea. ACRA CNC lathe, 16 x 40, 2-axis anilam 4200T controller

2 ea. LeBlonde 16 x 40 manual lathes with digital readouts

1 ea. Gorton Mastermill vertical knee mill, 10 x 42 table

1 ea. Cincinnati no. 2MH horizontal knee mill 10 ½ x 53 table

1 ea. Do-All vertical band saw, 16” throat depth

1 ea. Rockwell vertical band saw, 19” throat depth

1 ea. Wells horizontal band saw, 9” round capacity

1 ea. Wyson sheet metal shear, 12 ga. X 6’ capacity

1 ea. Lincoln Idealarc 300/300  AC/DC arc welder, Bernard water circulator, HW-20 and HW-18 TIG torches

1 ea. Miller Millermatic 251 wire welder

1 ea. Oxy-acetylene welding/cutting/brazing



Test and inspection

1 ea. Alcatel model ASM – 142 helium leak detector

1 ea. Fowler 12” optical comparator, 10x, 20x and 40x

2 ea. Granite surface plates, 24” x 24” 2 ledge, 24” x 18” 4 ledge



CAD/CAM

1 ea. AutoCAD 2017

1 ea edgeCAM ver. 2017 R1
